Industrial grade motherboard_ Embedded industrial control motherboard_ 3.5 inch industrial control motherboard

model	processor	internal storage	storage	expansion slot
EC3-EHLT-6C2L	upport for Intel ® Elkhart Lake J6412/J6413 Processor	1*SO-DIMM DDR4 3200MHz Max32GB	1SATAPort; 1M.2 M Key	1 * M.2 A Key, supporting WiFi/Bluetooth module expansion
EC3-SKYUT-6CD8	Support for Intel ® Kaby Lake & Skylake Processor	Supports single channel SO-DIMM, DDR4 2133MHz, Max32GB	1SATA Port ; 1mSATA	1*mPCIE,supporting WiFi/Bluetooth/4G module expansion
EC3-WHLUT-6C2L	Support Intel ® Core ™ Whiskeylake&Coffeelake-U processor	1*SO-DIMM DDR4 2400MHz Max32GB	1SATA3.0 ; 1M.2 M Key	1 * M.2 A Key, supporting WiFi/Bluetooth module expansion; 1 * M.2 B Key, supporting 3G/4G modules
LAN-GLKT-4LC	Support Intel® Gemini lake J4125/J4105/N4000 Processor	2*SO-DIMM DDR4 2400MHz Max8GB	1mSATA，1SATA3.0, 1*M.2 M Key	1 * MPIE, supporting WiFi / Bluetooth / 4G module expansion; 1 * SIM card slot
LAN-SKYUT2-6L	Support Intel I5(7200U, 7300U)/I7(7500U) Celeron 3865U	Built-in 2*SO-DIMM DDR4 2133MHz Max 64GB	1SATA3.0 1M-SATA	Built-in 1MINI-PCIE 2SIM，Support WIFI/4G
LAN-WHLUT-6LC	Support Intel® WhiskeyLake & CometLake CPU	Support dual channel O-DIMM DDR4 2666MHz Max64GB	1M.2 M Key，1SATA3.0， 1*mSATA	1M.2 A Key，Support WiFi / Bluetooth module expansion; 1 SIM card slot
NANO-WHLUT-4C2L	Support Intel ® Whistleylake & cometlake processor	Support dual channel SO-DIMM DDR4 2666mhz max64gb	1SATA3.0;1M.2 M Key	1 * MPIE, supporting WiFi / Bluetooth; 1 * SIM card slot; 1*M. 2 E Key
LAN-EHLT2-6LC	Support Intel ® Elkhart Lake J6412/J6413 processor	Support dual channel SO-DIMM DDR4 3200MHz Max32GB	1SATA3.0; 1mSATA	1 * mPCIE (USB signal), Wifi module supporting USB signal
DZ-GLKT-2C1L	Support for Intel ® Gemini Lake J4125/J4105/N4000 processor	Supports single channel SO-DIMM, DDR4 2400MHz, Max8GB	1*miniSATA	1 * miniPCIE, supporting WiFi/Bluetooth module expansion
EC3-J19TD-2C1L-GPOS	Support for Intel ® Bay Trail J1900/J1800/N2840 processors	Single channel SO-DIMM, DDR3L 1333MHz, Max8GB	Supports 1 * SATA and 1 * Mini SATA	Supports 1 * Mini PCIE (supports WiFi/Bluetooth modules)
EC3-GLKTD-2C1L-GPOS	Support for Intel ® Gemini Lake J4125/J4105/N4000 Processor	Supports single channel SO-DIMM, DDR4 2400MHz, Max8GB	1*mSATA	1*mPCIE，supporting WIFI/Bluetooth module
ZO-GLKT-4C2L-GPOS	Support for Intel Gemini lake J4125/J4105/N4000 Processor	Single channel SO-DIMM, DDR4 2133/2400MHz, Max8GB	1SATA, 1mSATA	Supports 1 * Mini PCIE slot (WIFI/Bluetooth module); 1 * SIM card slot
ZO-EHLT-4C2L-GPOS	Support for Intel ® Elkhart Lake J6412/J6413 CPU	Supports single channel SO-DIMM, DDR4 3200MHz, Max32GB	1mSATA；1SATA	1 * mPCIE, supporting WiFi/Bluetooth module expansion; 1 * SIM
ZO-GLKT-6C2L	Support Intel® Celeron® J4125 Processor	1*SO-DIMM DDR4 2133/2400MHz Max8GB	1SATA3.0; 1mSATA	Onboard 1*MiniPCIe，Support Wifi+Bluetooth /4G Module
ZO-EHLT-6C2L	Support Intel® customizations Elkhart LakeJ6412/J6413	1*SO-DIMM DDR4 2933/2666MHz Max16GB	1M.2 KeyB ; 1M.2 KeyE	Onboard 1*MiniPCIe，Support Wifi6+Bluetooth /4G Module
ZO-JSLT-6C2L	Support Intel® Jasper lake Series Processor	Single channel SO-DIMM DDR4 2933MHz Max16GB	1SATA3.0 1M.2 B Key（SATA SSD 2280mm）	1 * M.2 E Key (supports WiFi+Bluetooth) 1 * SIM (supports 4G/5G, supported through B KEY)
ZO-WHLUTA-6C2L	Intel®8th Whiskey lake&10thComet lake-U CPU	Support 2*SO-DIMM DDR4 2666/2400MHz Max32GB	1SATA3.0 1M.2 M Key(NVME PCIEx4/SATA Self	Support M.2Key B (Support 3G/4G Module；Option:5G)
ZO-TGLUTB-6C2L	support Intel®Tiger Lake-UP3 Processor (1135G7/1145G7 etc)	Supports dual channel SO-DIMM, DDR4 3200MHz, Max32GB	1 * M.2 M Key, supporting PCIEX2/SATA signals Select; 1 * SATA III (6.0 Gb/s)	1 * M.2 E Key, supporting Wifi6/Bluetooth module expansion
ZO-HM370TA-6C2L	Support for Intel ® 8th/9th/10th generation 8300H 9300H 10500H and other H-series processors	Dual channel SO-DIMM, DDR4 2666MHz, Max64GB	2SATA 1M.2 M Key（NVME PCIeX4/SATA SSD self-adaption ）	Supports 1 * M.2 A Key (supports WiFi+Bluetooth module); 1 * M.2 B Key (supporting 3G/4G modules); 1 * SIM slot
ITX-GLKT-AIO	Support for Intel Celeron ® Gemini Lake processor	Single channel SO-DIMM, DDR4 2400MHz, Max8GB	Supports 1 * SATA, 1 * M.2 M Key (supports SATA SSD)	Supports 1 * M.2 E Key (supports WiFi+Bluetooth module)
ITX-EHLT-AIO	Support for Intel ® Celeron Elkhart Lake J6412/J6413 processor	Supports single channel SO-DIMM, DDR4 3200MHz, Max32GB	1 * M.2 M Key (PCIEx2 and SATA adaptive); 1 * SATA	1 * M.2 E Key, supporting WiFi/Bluetooth module expansion
ZO-HM570T-AIO	Support for Intel ® Core ™ Tiger Lake 11th generation H-series processor	Supports dual channel SO-DIMM, DDR4 3200MHz, Max32GB	1SATA3.0 ; 1M.2 M Key	1 * M.2 E KEY, expandable WiFi+Bluetooth (supports wifi6)
EC3-J19T-6CD8	Support for Bayrail processors J1900/J1800/N2807	Supports 1 * SO-DIMM, DDR3L 1333MHz Max 8GB	Supports 1 * SATA2.0 and 1 * MINI-SATA	Supports 1 * Mini PCIE (for WIFI/Bluetooth/4G Card)
LAN-J1900T2-4L	Support Intel® celeron J1900/J1800 CPU	Dual Channel SO-DIMM DDR3L 1333MHz Max8GB	Support 1mATA、1SATA	Onboard 1*Mini-PCIe Support WIFI&4G
LAN-J1900T-6LC	Support Intel®Bay Trail J1900/1800	Single Channel SO-DIMM DDR3L 1333MHz Max8GB	Support 1 SATA2.0；1 CF Slot；1*mSATA	Onboard 1*Mini-PCIE ，Support Wifi/4G
LAN-1037UC-6LC	Support for Intel ® Ivy Bridge i3-3217U/i5-3317U Processor	Supports single channel SO-DIMM, DDR3 1600MHz, Max8GB	1mSATA;4SATA Port	1 * mPCIE, supporting WiFi/Bluetooth module expansion
LAN-3230MTH-6L	Support for Intel ® Bay Trail I5-3230M Processor	Supports single channel SO-DIMM, DDR3 1333MHz, Max8GB	1mSATA;2SATA Port	1 * mPCIE, supporting WiFi/Bluetooth module expansion
LAN-B85SFPESB-6L	Support Intel® Core™ Haswell CPU	Support dual chaneel SO-DIMM DDR3 1600MHz Max32GB	4SATA3.0;1mSATA	1mPCIE，Support Wifi/Bluetooth module extension(1SIMCard slot (optional)）
LAN-B150T-8L	Support Intel® LGA 1151 6th&7th Processor	Dual Channel SO-DIMM DDR4 2133/2400MHz Max32GB	Support 3SATA3.0 、1mSATA	?Support 1Mini-PCIe (For WIFI Card) 、1SIM
ZO-D2000P-7C2L	Support domestic Phytium Tengrui D2000 CPU; Quad core 8 threads; Main frequency 2.0-2.6GHz	Supports dual channel SO-DIMM, DDR4 2666MHz, Max32GB	1 * M.2 M Key, supporting PCIEX4/SATA signal adaptation; 3 * SATA3.0	/
NANO-J1900T-2C2L	Support for Intel ® Bayrail J1900/1800 processor	支持1*SO-DIMM，DDR3L-1333，Max.8GB	Support 1SATA 1Mini-SATA	1Mini-PCIE(For 4G/ WIFI ) 1SIM
ITX-J1900T4-6CD8	Supports Bay Trail J1900/J1800 processors	Single channel SO-DIMM DDR3L/1333 Max 8GB	Supports 1 * SATA, 1 * mSATA	Supports 1 * SATA, 1 * mSATA
ZO-H81P-12C	Support Intel LGA1150(Haswell) CPU	2*SO-DIMM，DDR3L 1600MHz ，16GB	2*SATA3.0	2MINI-PCIE(forM-SATA/WIFI ) 1SIM
ZO-H110PA-12C	Support Intel ® 7th & 6th Gen Core™ i Processor (LGA1151) TDP65W	Two 260-pin SO-DIMM up to 32GB DDR4	Support 2 x SATAIII，1 x mSATA	Support M.2 WIFI and 3G/4G module at the same time
ZO-H310P-12C	?Intel® H310 Chipset	2*SO-DIMM DDR4 2400/2666MHz 32GB	Support 2SATAIII，1mSATA	Support M.2 WIFI and 3G/4GModule
ZO-H310CTA Series Motherboard	Supports Intel i3/i5/i7 CoffeeLake-S/OfferLake-R-S Desktop 65W, LGA1151 processor	Supports 2 * SO-DIMM DDR4 2400/2666MHz up to 32GB	1*M.2 Key M, SATA /PCIe SSD	1*M.2 Key A，support WIFI+Bluetooth
ZO-H510P-12C	Supports Intel Rocket lake-S Desktop CPU	Dual channel SO-DIMM, DDR4 2666/3200MHz, Max128GB	Supports 2 * SATA 3.0, 1 * mSATA	1 * M.2 Key E, supporting WIFI, 3G/4G modules
ITX-J1900TEA-6C2L	Support Intel Baytrail Series CPU	1*DDR3L, Max Support8G	1SATA2.0 1MSATA	Support Mini PCIE WIFI+Bluetooth
ITX-J1900TF-10C2L	Support Baytrail Processor J1900/1800	1*SO-DIMM，DDR3L 1333MHz ，8GB	1*SATA2.0	2MINI-PCIE(forM-SATA/WIFI ) 1SIM
ZO-EHLTB-6C2L	Supports Intel's first IOTG custom Elkhart Lake J6412/J6413 processor	SO-DIMM DDR4 3200MHz Max16GB	1 * SATA3.0 interface	1 * M.2 Key B, supporting 4G/5G expansion modules
ZO-ADLNT-6C2L	Support Intel®Alder Lake-N (N305/N300/N100) Processo	Support SO-DIMM，DDR4 3200MHz ，Max16GB	1 * M.2 M Key, supporting PCIEX2/SATA 3.0 adaptation	1M.2 E Key，Support Wifi+Bluetooth； 1M.2 B Key, Support 3G/4G/5G module
ZO-HM570-1C2L	Support for Intel ® Core ™ 11th generation H-series processors	2*SO-DIMM DDR4 3200MHz Max64GB	2 * SATA, 1 * M.2 M Key (supports Pcie X4 and SATA SSD)	1 * M.2 E Key, (supports Pcie X1, WiFi+Bluetooth modules)
ZO-TGLUT2 -AIO	支持Intel®Tiger Lake-UP3 Processor (1135G7/1145G7等)	支持双通道SO-DIMM，DDR4 3200MHz ，Max32GB	1*M.2 M Key ，支持PCIEX4/SATA3.0自适应	1*M.2 E Key，支持Wifi/蓝牙模块扩展；
OPS-H310-CR1	Intel Coffee lake&Coffee lake-R I3/I5/I7 65W CPU	2*SO-DIMM，DDR4 2400/2666MHz	1 * 2.5 laptop hard drive interface (SATA HDD)	1*NGFF-M 2280 support SATA SSD;
M2121(OPS-H510-CR1)	Support for Intel ® 10/11 generation Core ™ I7/Core ™ I5/Core ™ I3/Pentium ®/ celeron ® Processor Comet Lake-S&Rocket Lake-S LGA1200 processor	2xSO-DIMM，DDR4 2666/2933/3200MHz Max128GB	1 x SATA interface (for 2.5 "hard drive) SATA3.0 1 x M.2 M Key (NGFF SATA3.0), supporting M.2 2280mm SATA SSD	/
M211J(OPS )	Domestic ZHAOXIN supports KX-6000 8-core 2.7GHz main frequency processor	2xSO-DIMM，DDR4 2400/2666MHz Max32GB	1xSATA interface (for 2.5"SSD)SATA3.0	/
M211M(OPS)	Domestic ZHAOXIN supports KX-6000 8-core 2.7GHz main frequency processor	Supports dual channel SO-DIMM DDR4 2666MT/s Max32GB	1xSATA interface (for 2.5"SSD)SATA3.0 1x7+15pin SATA interface (for 2.5"SSD)SATA 1xM.2 M Key(SATA SSD)	/
OPS-RPLPT-CR1	Support Intel® Alder Lake &Raptor Lake Processor	Support 2*DDR4 3200Hz 64G，support video codec	1 x M.2 M Key，2242/2280mm PCIEX4/SATA	1 x M.2 E Key（ WIFI6+Bluetooth）
OPS-RPLPST-CR1	Support for Intel ® 12/13th Intel Core ™ i7/i5/i3 Alder Lake &Raptor Lake Processor	2xSO-DIMM，DDR4 2666/2933/3200MHz Max64GB	1 x M.2 M Key, supporting 2242/2280mm PCIEX4/SATA signal adaptation; 1 * SATA Port	1 x M.2 E Key (supports WIFI6+Bluetooth module expansion)
OPS-8565UT	Support for Intel ® Celeron Whiskey&Cometlake processor	Dual channel SO-DIMM，DDR4 2400MHz ，Max64GB	1SATA_HDD；1M.2 M Key	1 * M.2 A Key, 1 * OSPCN expansion slot
M0141(OPS)	Supports Intel 11th Tiger Lake U platform processors	2xSO-DIMM，DDR4 3200MHz Max32GB	1 x SATA interface (for 2.5 "hard drive) SATA3.0 1 x M.2 Key M interface (NVMe), supporting M.2 2280mm SATA&PCIe SSDs	/
M2141(OPS)	Supports Intel 11th Tiger Lake U platform processors	2xSO-DIMM，DDR4 3200MHz Max32GB	1 x SATA interface (for 2.5 "hard drive) SATA3.0	/
ZO-GLKTF-10C2L	Support Intel® Celeron® J4125/J4105/N4000 Processor	1*SO-DIMM DDR4 2133/2400MHz Max8GB	Support 1SATA3.0、1mSATA ,SATA SSD	Onboard 1*MiniPCIe，Support Wifi+Bluetooth /4G Module
ZO-SKYUTA-6CD8	Support for Intel ® Kaby Lake&Sky Lake Processo	2*SO-DIMM DDR4 2133MHz Max32GB	1SATA 3.0 1M.2 Key M	1 * mPCIE, supporting WiFi/Bluetooth/4G module expansion
ZO-TGLUTA-2C2l	Support Intel®11generation 10nm Tigerlake-U Series CPU	1*SO-DIMM DDR4 2666/3200MHz Max64GB	Support 1*M.2 KeyB	(1*Expandmodule(Support WIFI+Bluetooth/4G)
LAN-3855UT-6L	Support Intel® Celeron® Processor 3855U	Support 1*SO-DIMM，DDR4 2133MHz 16GB	1SATA3.0、1Mini-SATA、1*M.2 B Key	1*M.2 B Key(For WIFI+Bluetooth Card)
OPS-HM370-CR1	The product meets the standard OPS-C design specifications	Supports DDR4 dual channel memory 3200MHz Max64G	1M.2 M Key（NGFF PCIe X and SATA self-adaption） 1SATA_HDD(For 2.5" SSD)	Support Key A NGFF M.2 interface, expandable WiFi+Bluetooth
OPS-HM570-CR1	Support for Intel ® Core Tiger Lake-H series processor	Supports DDR4 dual channel memory 3200MHz Max64G	1M.2 M Key（NGFF PCIe X and SATA self-adaption ）;1SATA_HDD(For 2.5" SSD)	Support Key A NGFF M.2 interface, expandable WiFi+Bluetooth
NANO-ADLN-1C2L	Support Intel®Alder Lake-N (N305/N100, etc) Processor	1*SO-DIMM DDR5 4800MHz Max16GB	1*M.2 M Key, support SATA/NVME adaptive	1*M.2 E Key, support Wifi6/Bluetooth module expansion;
ZO-H610T-AIO	Support Intel®12th/13th Alder Lake & Raptor Lake Processor	Support dual channel SO-DIMM, DDR4 3200MHz, Max64GB	1M.2 M Key, support NGFF/NVME by BOM; 2SATA3.0 Port	2*M.2 E Key, support PCIEX1/USN signal module expansion
ZO-TGLUT-6C4HD	Support Intel®Tiger Lake-UP3/H35 Processor (1135G7/11390H, etc)	Support dual channel SO-DIMM, DDR4 3200MHz, Max32GB	1M.2 M Key, support PCIEX4/SATA signal selected by BOM;1SATAⅢ(6.0 Gb/s)	1*M.2 E Key, support Wifi6/Bluetooth module expansion;
